B402 PTZ Series

22X/25X Smart Infrared POE Network PTZ Dome Camera

22X/25X Optical Zoom · Human Detection · Two-Way Audio · Max 128G On Board Storage · ONVIF · DWDR · 3D DNR · IP66 Waterproof
    Products
      4.5 INCH Infrared Speed Dome Camera 22X/25X with POE,Two-Way Audio
    · 265/H.265/H.264 Encoding,Saving Half Storage Capacity with Our NVR.
    · Horizontal Angle:0-360°,Vertical Angle 0-90°,Pan 0-30°/S /Tilt Speed 0-20°/S.
    · Support 128pcs Preset Points,Crusing,Guarding Point
    · 6PCS Infrared Leds,IR Distance up to 60m.
    · AI Humanoid Detection/Tracking,Vehicle Detection,Motion Detection Alarm.
    · Built-in TF Card Slot, Max Support 128G(512G requires high quality)..
    · DC12V / POE(IEEE.802.3af),Support P2P.
    · AGC,DWDR,3D DNR, BLC,4KV Lighting Protection,Metal and Plastic PTZ Dome,IP66 Waterproof.
    Model Number B402TS40Z1A2-P
    Camera
    Image Sensor 1/3" CMOS Image Sensor
    Resolution 4.0MP
    Code Format H.265[$add]/H.265/H.264
    Output Bit Rate 200Kbps~8000Kbps
    Video Resolution 2560×1440@25fps
    Audio Compression Standard G711u/64Kbps
    Min. Illumination Color: 0.001Lux @F1.2, B/W: 0Lux with IR on
    IR LEDs 6pcs Infrared Leds
    IR Distance 60m IR distance
    Day & Night Mode B & W
    Auto Control Warm Light Auto
    Image Quality Adjust Brightness,contrast,sharpness,saturation,tint
    WDR D-WDR
    DNR 3D DNR
    White Balance Auto/Indoor/Outdoor/Manual
    Gain Control High/Middle/Low
    Lens
    Lens 4.7-84.6mm
    Optical Zoom 22X Optical Zoom
    E-Shuttle 1/1 ~ 1/30000s
    Near Focus 100mm ~ 1000mm (Near ~Far Focus)
    Zoom Speed About 4S(Optics Far-Tele)
    Lens Initialization Built-in
    PTZ
    Pan 0~360°
    Horizontal Speed 0~ 30°/ s
    Tilt 0~90°
    Vertical Speed 0~ 20°/ s
    Preset 128 PCS
    Cruise Support
    A-B Scan Support
    Guard Point Support
    Home Position Support, preset position, cruise, linear scan option
    Power-off Memory Support
    Event
    Detection Human Detection and Tracking,Motion Detection
    Alarm Support motion detection alarm linkage,Support center reminder and screen pop-up linkage after motion detection alarm.
    NETWORK
    Network Protocol HTTP,TCP/IP,IPv4,DHCP,NTP,RTSP,ONVIF,P2P,PPTP,GB/T28181,etc
    Connection Protocol ONVIF2.4
    ONVIF Support
    P2P Support
    Mobile Remote Control Support Android & iOS system mobile to access
    PC Support
    Web Access Support
    Interface
    Network Interface 1*RJ45 10M/100M Self-adaptation Ethernet Port
    Power 1pcs DC female head
    Audio Built-in microphone and speaker
    Storage Built-in Micro TF card slot, Max 128G
    Alarm I/O No
    General
    Power POE /DC12V 3A
    Working Temperature -20 °C to 60 °C
    Working Humidity <90% (no frostless)
    Power Consumption ≤18W
    Housing Plastic and Metal PTZ Dome
    Protection TVS3000V lightning protection, surge protection, voltage transient protection
    Weather Proof IP66
    Model Number B402TS50Z1A2-P
    Camera
    Image Sensor 1/2.7" CMOS Sensor
    Resolution 5.0MP 2880x1620@25fps
    Code Format H.265[$add]/H.265/H.264
    Compressed Output Bit Rate 200Kbps~8000Kbps
    Audio Compression Standard G.711
    Min. Illumination Color 0.001Lux @ F1.2(AGC ON),B/W:0LUX(IR ON)
    Day & Night Mode B&W
    IR LEDs 6pcs Infrared Leds
    IR Distance 60m IR distance
    E-Shutter 1/5s~1/100000S
    WDR Digital WDR
    DNR 2D/3D DNR
    BLC Support
    Exposure Support
    White Balance Support
    Gain Control Support
    Lens
    Lens 4.7-84.6mm Lens
    Optical Zoom 22X Optical Zoom
    E-Shuttle 1/1 ~ 1/30000s
    Zoom Speed About 4S(Optics Far-Tele)
    Lens Initialization Built-in
    PTZ
    Pan 0~360°
    Horizontal Speed 0~ 30°/ s
    Tilt 0~90°
    Vertical Speed 0~ 20°/ s
    Preset 128 PCS
    Cruise Support
    A-B Scan Support
    Guard Point Support
    Home Position Support, preset position, cruise, linear scan option
    Power-off Memory Support
    Event
    Human Detection Support human detection and tracking
    Motion Detection Support
    Alarm Linkage Support motion detection alarm linkage,Support center reminder and screen pop-up linkage after motion detection alarm.
    NETWORK
    Network Protocol HTTP,TCP/IP,IPv4,DHCP,NTP,RTSP,ONVIF,P2P,PPTP,GB/T28181,etc
    Connection Protocol ONVIF2.4
    P2P Support
    Mobile Remote Control Support Android & iOS system mobile to access
    PC Support
    Web Access Support
    Interface
    Network Interface 1*RJ45 10M/100M self-adaptive Ethernet Port
    Power 1pcs DC female head
    Storage Built-in Micro TF card slot, Max 128G,timing recording and alarm recording storage
    Alarm I/O No
    Audio Built-in microphone and speaker
    General
    Power DC12V 3A / POE
    POE Support
    Working Temperature -10 °C to 50 °C
    Working Humidity <90%
    Power Consumption Max 16W
    Housing Metal and Plastic PTZ Dome
    Protection TVS3000V lightning protection, surge protection, voltage transient protection
    Weather Proof IP66
    Model Number B402TS50Z5A2-P
    Camera
    Image Sensor 1/2.7" CMOS Sensor
    Resolution 5.0MP 2880x1620@25fps
    Code Format H.265[$add]/H.265/H.264
    Compressed Output Bit Rate 200Kbps~8000Kbps
    Audio Compression Standard G.711
    Min. Illumination Color 0.001Lux @ F1.2(AGC ON),B/W:0LUX(IR ON)
    Day & Night Mode B&W
    IR LEDs 6pcs Infrared Leds
    IR Distance 60m IR distance
    E-Shutter 1/5s~1/100000S
    WDR Digital WDR
    DNR 2D/3D DNR
    BLC Support
    Exposure Support
    White Balance Support
    Gain Control Support
    Lens
    Lens 5.3-130mm Lens
    Optical Zoom 25X Optical Zoom
    E-Shuttle 1/1 ~ 1/30000s
    Zoom Speed About 4S(Optics Far-Tele)
    Lens Initialization Built-in
    PTZ
    Pan 0 °~ 360°
    Horizontal Speed 0 ~200°/s
    Tilt 0~90°
    Vertical Speed 0 ~120°/s
    Preset 128 PCS
    Cruise Support
    A-B Scan Support
    Guard Point Support
    Home Position Support, preset position, cruise, linear scan option
    Power-off Memory Support
    Event
    Human Detection Support human detection and tracking
    Motion Detection Support
    Alarm Linkage Support motion detection alarm linkage,Support center reminder and screen pop-up linkage after motion detection alarm.
    NETWORK
    Network Protocol HTTP,TCP/IP,IPv4,DHCP,NTP,RTSP,ONVIF,P2P,PPTP,GB/T28181,etc
    Connection Protocol ONVIF2.4
    P2P Support
    Mobile Remote Control Support Android & iOS system mobile to access
    PC Support
    Web Access Support
    Interface
    Network Interface 1*RJ45 10M/100M self-adaptive Ethernet Port
    Power 1pcs DC female head
    Storage Built-in Micro TF card slot, Max 128G,timing recording and alarm recording storage
    Alarm I/O No
    Audio Built-in microphone and speaker
    General
    Power DC12V 3A / POE
    POE Support
    Working Temperature -10 °C to 50 °C
    Working Humidity <90%
    Power Consumption Max 20W
    Housing Metal and Plastic PTZ Dome
    Protection TVS3000V lightning protection, surge protection, voltage transient protection
    Weather Proof IP66
    Model Number B402TS80Z1A2-P
    Camera
    Image Sensor 1/2.8" CMOS Sensor
    Resolution 8.0MP
    Code Format H265/H264
    Compressed Output Bit Rate 200Kbps~8000Kbps
    Video Resolution Main stream: 3840x2160@20fpsSub-stream: 720x480/VGA(640x480)/360P/QVGA@30fps,etc.
    Audio Compression Standard G.711-a,G.711-u
    Min. Illumination B/W:0LUX/F1.2,AGC ON)
    Day & Night Mode B&W
    IR LEDs 6pcs Infrared Leds
    IR Distance 60m IR distance
    Lens
    Lens Auto-Focus 4.5-99mm Lens
    Optical Zoom 22X Optical Zoom
    Near Focus 100m~1000mm(N~T)
    PTZ
    Pan 0~360°
    Horizontal Speed 0~ 30°/ s
    Tilt 0~90°
    Vertical Speed 0~ 20°/ s
    Preset 128 PCS
    Cruise Support
    Auto Line Scan Support
    Two Points Scan Support,set at will
    Zoom Camera Works with most zoom camera(Specific camera protocols can be customized)
    Control Method RS485
    Power-off Protection Automatic run memory function after power off
    Function
    S/N ≥52dB
    Smart Alarm AI humanoid Detection,motion detection, occlusion alarm, privacy masking
    Alarm Linkage The mobile detection alarm is pushed to the APP
    E-Shutter 1/5s~1/100000S
    WDR Digital WDR
    DNR 3D DNR
    BLC Auto/manual
    Exposure Auto
    Image Quality Adjustment Brightness,Contrast,Sharpness and saturation can be adjusted
    NETWORK
    Network Protocol HTTP,TCP/IP,IPv4,DHCP,NTP,RTSP,ONVIF,P2P,PPTP,GB/T28181,etc
    Connection Protocol ONVIF2.4
    Mobile Remote Control Support Android & iOS system mobile to access
    PC Support
    Security Mechanism Password protection,multi-user access control
    Interface
    Network Interface 1*RJ45 10M/100M self-adaptive Ethernet Port
    Storage Support 128G
    Alarm I/O No
    Audio MIC line input and line output
    General
    Power DC12V3A / POE
    POE Yes
    Working Temperature -10 °C to 50 °C
    Working Humidity <90%
    Power Consumption Max 18W
    Housing Metal and Plastic PTZ Dome
    Protection TVS3000V lightning protection, surge protection, voltage transient protection
    Weather Proof IP66
