| Model | NVR-4K8116I-P16/A |
| System | |
| Operating System | Embedded LINUX |
| Video & Audio | |
| Incoming Bandwidth | 80Mbps |
| IPC Input | 4K/5MP/4MP/3MP/2MP/960P/720P |
| Video & Audio Decoding | |
| IP Channel Resolution | Main stream: up to 3840×2160Auxiliary stream: D1/CIF |
| Video Decoding | Smart H.265/H.265 /H.264 |
| Audio Decoding | G.711 |
| Preview/Playback | 8MP/5MP/4MP/3MP/1080p/960p/720p |
| Multi-screen Split | Support 1/2/4/6/8/9/10/16 screen real-time preview |
| Split Screen/Decoding | 1(4K),4(4*1080P),6(4MP[$add]5*D1),8(4MP[$add]7*D1),9(9*D1),16(16*D1) |
| Recording & Playback | |
| Recording Mode | Timing and alarm recording, Time recording, Alarm recording |
| Playback | NVR synchronous playback 4CH (1*4K)IMS client support max 4CH remote video playback |
| Playback Mode | Search by time, calendar, event, channel |
| Other Function | |
| Smart Functions | Alarm Recording includes: Humanoid Detection, Line-Crossing Detection, Area Intrusion, Loitering, Absent Detection, Vehicle Illegal Parking, Vehicle Retrograde (need front end IPC supported) |
| Motion Detection | Support |
| Buzzer | Support buzzer alarm |
| PA System | Support |
| Storage & Backup | |
| SATA | 1*SATA HDD |
| Capacity | Max 16TB HDD |
| E-SATA | No |
| Backup Mode | Portable hard disk/USB Device |
| Network | |
| Network Protocols | DCP/IP,IPv4,DHCP,NTP,RTSP,ONVIF,P2P,SMTP,GB28181,etc. |
| ONVIF | Support |
| POE Standard | Single port max 15.4W(IEEE802.3af),Single port max 30W(IEEE802.3at) |
| P2P | Support |
| APP | iPhone, Android |
| PC | Support |
| User Management | Maximum support 32 local user |
| Online Upgrade | Supports online NVR upgrade |
| IPC Upgrade | Support (specified model IPC) |
| Other | Support Channel Tour Round GroupingRTMP push |
| Interface | |
| Network Interface | 1pcs RJ45 10M/100M self-adaptive Ethernet interface |
| USB Interface | 2pcs USB2.0 Interfaces |
| Video Output | VGA: 1CH,1920×1080,1280×1024,1280×720,1024×768 |
| HDMI:1CH,3840*2160, 1920×1080,1280×1024,1280×720,1024×768 | |
| Audio Output | Support HDMI audio output |
| Alarm | No |
| RS485 | No |
| General | |
| Installation | Desktop Installation |
| Power Supply | DC52V 4.62A |
| Consumption | ≤100W |
| Working Conditions | Temperature:-10℃- [$add]55℃ , Humidity: 10%∼90% |
| Product Dimension | |
| Size (mm) | 210*255*42mm(W×L×H) |
