| Model Number | E1AQ506F-P |
| Camera | |
| Image Sensor | 1/2.8" SONY low illumination CMOS sensor |
| Min. Illumination | Color: 0.005 Lux @ (F1.6, AGC ON),B/W: 0 Lux with IR |
| Shutter Time | Auto(1/5 - 1/100000) |
| Lens | |
| Lens Type | [email protected] Fixed Lens |
| Lens Resolution | 5MP |
| Illuminator | |
| Light Distance | IR 25~30m |
| IR LEDs | 3pcs IR Array LEDs |
| Day/Night | Infrared Mode: B/W |
| Video | |
| Max. Image Resolution | 5MP(2592x1904)@25fps |
| Video Compression | S.265/H.265/H.264 |
| Frame Rate | Main Stream: 5MP(2592x1904)/4MP(2560x1440)/3MP(2304x1296)/2MP(1920x1080)@25fpsSub Stream: D1(720x576)/VGA (640x480)/Q720P(640x360) |
| Video Bit Rate | Fixed code rate ,variable code rate(main stream:1024Kbps-8Mbps) |
| Image Settings | Brightness,contrast,saturation,sharpness,chroma |
| White Balance | Auto / Manual |
| Exposure Control | HLC/BLC, Shutter Priority / Gain Priority |
| WDR | Real WDR |
| Noise Reduction | 3D NR (Off/Low/Mid-Low/Mid/Mid-High/High) |
| Defog | Off/On |
| Mirror | Off/horizontal mirror/vertical mirror/180° flip |
| Character Overlay(OSD) | Support time OSD/Title OSD, Single-line/Multi-line OSD |
| Audio | |
| Audio Input | No |
| Audio Output | No |
| Network | |
| Network Interface | 1*RJ45 10M/100M Self-adaptation Ethernet Port |
| Networking Protocol | TCP/IP,UDP,HTTP,HTTPS,DHCP,RTSP,DDNS,PPPOE,UPNP,RTMP,FTP |
| Connection Protocol | ONVIF,GB28181 |
| APP | No, through the NVR |
| PC | Support |
| Web Access | Support HTML5 remote login operation(Free plug-in) |
| Preview Simultaneously Video Number | 4 |
| Device Abnormal Inspection | Support network broken alarm, IP conflict alarm, illegal visiting alarm |
| Security Mode | Authorized user name and password,HTTPS encryption,AES connecting encryption, RTSP vertification |
| Event | |
| Alarm | Motion Detection Alarm, AI Humanoid Detection and Tracking Alarm |
| Linkage | Upload to FTP, Upload Picture, send email, trigger recording, trigger capture,Arming time support 24h arming/ night arming /customized arming |
| Basic Event | |
| Motion Detection | Set detection area,can set multi-level sensitivity |
| Privacy Mask Alarm | Support 1 area |
| Privacy Mask | Support 4 area |
| Smart Event | |
| Human Detection | It can detect target ≤5-10 persons at the same time |
| Humanoid pixel ≥40X40 | |
| Detection Ratio ≥99%(meet above requirement) | |
| Capture Corresponding Speed ≤1s | |
| Support specified area detection, default full screen | |
| Error detection rate 2% or less | |
| Maximum detection frame rate is 5fps /s | |
| Detection Part: people with any posture including half body,head,hand shoulder | |
| Detection Mode: support static and dynamic humanoid detection | |
| Interface | |
| Ethernet Interface | 1 RJ45 10M/100M self-adaptive Ethernet port |
| On-Board Storage | No |
| Alarm | No |
| RS-485 | No |
| Reset | No |
| General | |
| Explosion-proof | ExD IIC T6 Gb/ ExtD A21 IP68 T80℃ |
| Protection Grade | IP68 |
| Shell Material | 304 stainless steel |
| Power Supply | DC12V±10% /POE |
| Power Consumption | Max 10W |
| Surge Protection | 6KV |
| Working Temperature | -10 °C to 50 °C |
| Working Humidity | 0%-90% (Non-condensing) |
